Single Phase 220V/110V 8" 12" 278 Oscillations Tap Sieve Shakers for Particle Sizing Analysis
Overview of Single Phase 220V/110V 8" 12" 278 Oscillations Tap Sieve Shakers for Particle Sizing Analysis:
AT200tap tap test sieve shaker is also known as the tap vibration test sieve, tap vibration test screen, standard tap sieve shaker, standard tapping vibration test screen, standard slap vibration test sieve, ro-tap sieve shaker, ro-tap test sieve shaker, ro-tap sieve, rotap sieve shaker, rotap test sieve shaker, rotap sieve, ro-tap motorized sieve shaker, rotap motorized sieve shaker, rotap screen machine, ro-tap screen machine, ro-tap testing sieve shaker, rotap testing sieve shaker, slap vibrating screen, panting sieve machine, sand sieving machine, sand sieving machine, flapping vibration test screen machine, beating vibration test sieve, classifier, jigging sieve, sieve shaker, sieving machine, shaking sieve, screen shaker etc.
The AT200tap tap test sieve shaker can be equipped with sound-proof cover or shield according to the requirement.
The AT200tap tap test sieve shaker (synchronous belt type) made by our company is in accordance with international products. The working parameters meet the national standards. With test sieve and sample sieve, it can be used for metallurgy, chemical industry, abrasive, super hard materials, feed, food, medicine and other industries screening production and inspection of the powder materials.
Working Principle of Single Phase 220V/110V 8" 12" 278 Oscillations Tap Sieve Shakers for Particle Sizing Analysis:
The motor drives the gear speed change through the synchronous belt, making the main shaft rotate. And then the main shaft drives the eccentric wheel to make the slide plate drive the test sieve shake left and right. At the same time, it drives the top gear rotate, strike the hammer and slap the test sieve, making materials in the test sieve and sample sieve screen layer by layer. So people can accurately obtain the materials of multiple particle size ranges at the same time, achieving accurate and rapid screening purposes.
Features of Single Phase 220V/110V 8" 12" 278 Oscillations Tap Sieve Shakers for Particle Sizing Analysis:
1. The reproducibility of the test result is good.
2. It can be equipped with 200mm or 205mm sieves, 1~8 layers.
3. Simple operation, free of refueling, clean, hygienic and convenient.
4. Selection of high quality accessories, reasonable structure, low failure rate.
5. Complete synchronous belt conduction power, quick and easy maintenance.
6. Sound protecting cover can be installed to avoid noise.
7. Accurate transmission, good consistency.
8. Long life and low maintenance cost.
9. High screening efficiency.
10. Clean.
Technical Parameters of Single Phase 220V/110V 8" 12" 278 Oscillations Tap Sieve Shakers for Particle Sizing Analysis:
NO.
Name
Value
Unit
1
Diameter
300, 200, 150, 100, 75
mm
2
Layer
5~7
Layer
3
Shaking Times
290±10
times/min
4
Tapping Times
156±10
times/min
5
Reciprocating Trip
25
mm
6
Tapping Height
38±6
mm
7
Power
370
W
8
Voltage
380, 220
V
9
Dimensions
H700*L460*W420
mm
10
Weight
80
KG
Note: All technical data and dimensions of our products shall be subject to physical objects.
Application of Single Phase 220V/110V 8" 12" 278 Oscillations Tap Sieve Shakers for Particle Sizing Analysis:
Our AT200tap tap sieve shaker is ainly used in diamond and other materials of high value, requiring accurate screening of the abrasive industry. It is widely used in metallurgy, powder, chemical, pharmaceutical, building materials, geology, feed, defense and other departments of scientific research and production, laboratory, and quality inspection room, for particle and powdery materials granular structure and sundries amount of standard screening, filtering and inspection sieve test. The device is equipped with timing device to ensure the accuracy and repeatability of the user test results.
