Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder

Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder

Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder
Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder
Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AYGO
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~35 work days after order confirmed
Payment Terms: T/T, L/C
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description
Movement: Three Dimensional Vibration Motion Handling Capacity: 2~4 Times Than General-purpose Rotary Vibrating Screen
Drive Device: General-purpose Motor, Verticle Vibratory Agent, Upper Weight, Lower Weight, V-pulley, V-belt Motor: Ordinary Motor Or Explosion-proof Motor Drive, Not Vibrating Motor
Diameter: 500mm, 800mm, 1000mm, 1200mm, 1500mm Screen Structure: Flange Type Screen Structure
Screen Material: Stainless Steel Mesh, Nylon Mesh (optional) Application: Wheat Flour, Starch, Silica, Limestone, Galss, Sugar Etc.
Highlight:

metal powder vibrating sieve

,

vibrating sieve for metal powder

,

metal powder sieving machine

Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder







Introduction of Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder:

Our AYGO circular three-dimensional vibration multi-deck screening machine do not use vibrating motors but instead use general-purpose motors, keeping the vibratory agent and motor separate.

  The upper and lower weights mounted to the top and bottom of the vibratory agent enable the three-dimensional movement (horizontal, verticle and oblique) and treatments according to the material properly.

The optimal adjustment of vibrations and revolutions is possible by integrating the inverter control to the machine.

  Our AYGO series vibrating sieve machines meet the market demand for screening that is faster, more reliable and more precise. The doubling of amplitude achieves two to four times greater screening capacity than the conventional types. Moreover, the vibration pattern can be altered in accordance with the materials.



Comparison Between Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder and Conventional Rotary Vibrating Screen:

Name Model Drive Device Movement Screening Effect
Ordinary Rotary Vibrating Screen AY vertical vibrating motor three dimensional vibration motion
Powerful Rotary Vibrating Screen AYGO general-purpose motor + verticle vibratory agent three dimensional vibration motion 2~4 times than ordinary vibro sifter



Working Principle of Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder:

  Generally, the vibrating sieve vibrate with the screen surface as the center, and the weights mounted at both shaft ends of the vibratory agent creat the vibrations. The revolution of the upper weight generates horizontal vibrations to the screen surface and moves the materials fed onto the center of the screen in the direction of revolution. The lower weight generates vertical vibrations and moves the materials toward the periphery. These vibrations are combined to generate special three-dimensional movements at the screen. Shifting the phase of the upper weight in relation to the lower weight changes the vibratory behavior, thus creating the optimal movement for the materials being treated.



Characteristics of Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder:

1. the longitudinal acceleration of powerful rotary vibrating screen is twice as much as the original product rotary sieve (compared with our company)

2. the handling capacity is 2~4 times that of the original product (compared with our company). Materials those are difficult to screen can hardly clog up the mesh, and the output is also doubled.

3. the noise is obviously decreased. Small volume, convenient movement, no installation foundation

4. with more powerful vibration force and solid structure

5. more convenient to replace screen mesh

6. ordinary motor drive. Explosion-proof motor drive is also available



Overall Structure of Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder:



Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 0



Screen Structure of Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder:



Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 1 Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 2 Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 3
Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 4 Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 5 Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 6

Inner Ring:

The screen mounting part (flange) is positioned on the screen frame (particle contacting side). There is no leakage of powder or liquid (aqueous solution) regardless of whether the screen apertures are large or small.

Outer Ring:

The screen flange is positioned outside the screen frame. The effective screen area reaches the periphery to the discharge opening, and the screening function is available over the entire screen. This also avoids the risks whereby the residual materials above the sieve drop through it, the steel wires unravel, and worn-off powder or foreigh materials are intermixed with the materials.

Cassette:

Dismantling and assembly can be done via the simple cassette method, which is easy enough for inexperienced workers to use. The work efficiency in changing products will improve signilicantly, since such work is done simply by preparing cassette frames. You do not have to waste any more screens. You do not have to waste any more screens. Due to its simple method of assembly/disassembly, it is best for screening products that necessitate frequent cleaning.



The direction of material movement on the screen surface depends on the phase angle of the upper and lower eccentric blocks.

Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 7 Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 8 Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 9
Phase Angle 0° Phase Angle 45° Phase Angle 90°
The material on the screen surface moves linearly along the outer circumference. The material on the screen surface moves spirally in the outer circumferential direction. The material on the screen surface moves spirally toward the center.



Some Specifications of Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder:



Diameter (mm)

500

800

1000

1200

1500
Motor (KW) 0.75 1.5 2.2 3.7 3.7
Vibration Number

1800 (V.P.M)

1500 (V.P.M)

1200 (V.P.M)
Material

Part contact powder: stainless steel 304

Others: hot dip galvanizing on stainless steel 400


Dimensions​ of Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder:

Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder 10

Model A B C D E F G H I J K L

AYGO-500-1

AYGO-500-2

AYGO-500-3

550

100

490

375

80

80

438

542

 -- --

100

 723
647 -- 828
647 752 933

AYGO-800-1

AYGO-800-2

AYGO-800-3

815

150

785

575

100

100

495

638

 -- --

127

 929
770 -- 1061
770 902 1193

AYGO-1000-1

AYGO-1000-2

AYGO-1000-3

815

200

917

675

160

100

508

642

 -- --

125

 957
774 -- 1089
774 906 1221

AYGO-1200-1

AYGO-1200-2

AYGO-1200-3

1030

250

1112

780

160

160

685

865

 -- --

165

 1200
1035 -- 1370
1035 1205 1540

AYGO-1500-1

AYGO-1500-2

AYGO-1500-3

1030

250

1395

950

200

160

685

880

 -- --

155

 1236
1040 -- 1396
1040 1200

1556



Application for Stainless Steel High Efficiency Large Capacity 1800 RPM Rotary Vibrating Sieve for Metal Powder:

1. Ceramics: silica, limestone, glass, foundry sand, ceramics, tile materials
2. Chemicals: toner, carbon, powder paint, cellulose, pigment, calcium carbonate
3. Food: flour, tea, sugar, starch, coffee beans, curry powder
4. Metals: ferrous powder, silver powder, copper powder, shot-blast beads, abrasives
5. Pharmaceuticals: powdered medicines, herbal medicines, amino acid, citric acid, corn starch
6. Pollution: asbestos collection



Name Specific Gravity Particle Size (mesh) Powerful Type Ordinary Type Capability Ratio
1 Chemicals 0.5

400#

500#

 AYGO-600-2S 36Kg/h AY-600-2S 10Kg/h 3.35
2 Resin 0.9 80# AYGO-1000-1S 660Kg/h AY-1000-1S 283Kg/h 2.33
3 Silicide Alkali 1.3 60# AYGO-1000-1S 970Kg/h AY-1000-1S 800Kg/h 1.21
4 Silica 0.9 100# AYGO-1000-1S 500Kg/h AY-1000-1S 280Kg/h 1.79
5 Processed Silica 0.5 100# AYGO-1000-1S 32Kg/h AY-1000-1S 28Kg/h 2.74
6 Silica Sand 1.5 35# AYGO-1000-1S 2000Kg/h AY-1000-1S 1000Kg/h 2.00
7 Pharmaceuticals 0.6

14#

50#

 AYGO-600-2S 38Kg/h AY-600-2S 12Kg/h 3.35
8 Abrasive Material 2.5 32# AYGO-800-1S 3700Kg/h AY-800-1S 560Kg/h 6.60
