1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity

1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity

1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity
1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity
1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AM
Payment & Shipping Terms:
Price: E-mail: sale@aarealmachine.com
Payment Terms: WhatsApp: 0086-15637361027
Supply Ability: https://www.aarealmachine.com
Contact Now
Detailed Product Description
Screening Accuracy: High Up To 90% ~ 99.9% Movement: Imitate The Manual Screening Action, Involute Spiral Tumbling Motion
Machine Diameter: 2000mm Layers Of Screen: 3
Screen Structure: Whole Adhesive Screen Mesh Cleaning Method: Ultrasonic System, Which Includes Power Boxes And Transducer
Mesh Size: 60 Mesh, 80 Mesh, 200 Mesh Motor Brand: China Made Brand, Siemens, ABB, BEGEMA Etc.
Highlight:

tumbler screen for silica sand

,

silica sand tumbler screen

,

silica sand screening machine

1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity





Overview of 1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity​:

  AAREAL tumbler screening machines have been setting the standards in fine and ultra-fine screening of dry bulk materials. Precise separation steps with up to seven fractions, as well as the wide range of available sieve cleaning options, characterize the quality and durability of these systems.

  Unlike the typical vibratory or gyratory screening machine, the tumbler screening machine incorporates a unique three-dimensional tumbling motion providing the gentlest screening possible. This motion prevents delicate, friable material from being broken resulting in less undesirable fine generation and dust levels. Even the most difficult materials, which tend to blind screens, are screened efficiently by utilizing the proper anti-blinding systems including motor driven brushes and/or air knives that are unique to tumbler type screening machines.

  AAREAL tumbler screen machines are used for bulk material grading, safety screening, and dedusting in all industrial sectors. They are particularly well-suited to the fine and extremely fine screening of dry bulk materials and precise grading with up to 6 particle sizes. Our AM model tumbler screen machine features a range of customization options designed to meet extremely demanding requirements, as well as a broad variety of additional equipment options. Among these, the number of available screen cleaning systems is particularly worth mentioning, with balls, brushes, ultrasonic system, and various combinations being of these options are available to prevent blinding and maintain efficient screening.



Important Information About 1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity​ You Won't Miss:

Motion  involute spiral tumbling motion
Screening Accuracy  upto 90%~99.9%
Mesh Cleaning Method  bouncing balls cleaning, ultrasonic system cleaning, brush cleaning, air   cleaning, ultrasonic air cleaning, air brush cleaning
Screen Structure  adhesive screen, or splicing segmented screen etc.
Layers of Screen  1~5 layers of screen with 6 outlets (suggest 1~3 layers)
Diameter  600mm, 1000mm, 1200mm, 1400mm, 1500mm, 1600mm, 1800mm,   2000mm, 2100mm, 2300mm etc.
Advantages  soft rock screening will not destroy the particles original structure of the   material and not easy to produce static electricity
Optional pneumatic lifting devices, quick clamps etc.
Application  can be used for material that is flammable, explosive and easy to   generate static
Motor Brand  China made brand, Siemens, ABB etc.



Application of 1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity​:

AAREAL Tumbler screening machines are used for classification, protective screening, and dust removal of bulk materials in nearly all industries, including construction materials, chemicals, mining, pharmaceuticals, animal feed, and food processing, such as:


Activated Carbon

Food and spices

Sugar

Salt
Chemical
Rubber
Fertilizer

Plastics
Medicine
Wood and Plywood
Fodder
Mining
Metallurgy
Renewable industry



Characteristics​ of 1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity​:

1. A very high sieving efficiency of 90% -99%.
2. Sieve aperture will not be blocked.
3. Can have up to 6 outlets with 5 layers of screens.
4. Has lower acceleration speed compared to other vibrating screens.
5. Can have up to six levels of separation.
6. Has a bag of enclosed cleaning dust.
7. Can be safely used with minimal supervision.
8. Easy to clean and maintain.

9. Dust and gas tight.
10. Produces less noise compared to other brands.
11. Has a sturdy internal and external screen frame.
12. Can remain balanced even with the heavy sieving workload.
13. Connected to an ultrasonic mesh cleaning device.
14. Can divide powder particles according to size.
15. Can separate material particles from foreign materials mixed within it.
16. Can perform the solid-liquid separation.
17. Made with high-standard steel to withstand heavy-duty sieving production.
18. Will not destroy sensitive product particles.


Working Principle of 1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity​:

  While the tumbler screening machine is running, its radial inclination ensures that the material being screened moves from the center of the screen outwards, while its tangential inclination makes the material move in circular fashion on the screen. The interaction between the two resulting forces makes the particles being screened move in a spiral pattern on the screen fabric, ensuring that the particles stay a long time on the screen. This, in turn, enables the machine to achieve an optimum level of grading accuracy with respect to the particle size ranges while simultaneously minimizing oversize and fines contamination.

The movement of a tumbler screening machine is usually compared with simple hand screening. The product is continuously fed into the center of the top screen, from where it spreads out evenly to the outside across the entire screening surface. The finer particles fall through the screen near the center and the coarser ones successively towards the periphery. The material is moved in a spiral pattern with increasing acceleration of the particles the further they are from the centre, with the result that even those particles which are almost the same size as the screen mesh are screened. All the separated fractions are discharged through the lateral outlets. The screening process is repeated again and again on each deck.

1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity 01500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity 1





1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity 2



Machine Parts:
1. Feeding Inlet
2. Top Cover
3. Observation Hole
4. Screen Frame
5. Sealing Ring
6. Discharging
7. Wire Frame
8. Beam Ring
9. Bottom Frame
10. Pivot Assembly
11. Adjustment Block
12. Screen
13. Vibration Plate
14. Adjustable Bolt
15. Swing Body
16. Choke Spring
17. Main shaft assembly
18. Pulley
19. Base
20. Inspection Hole
21. Motor



Technical Parameters of 1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity​:

Model Screen Area (m²) Layers of Screen Motor Power (KW)
AM-600 0.28 1~5 (suggest 1~3) 0.25
AM-1000 0.72 1~5 (suggest 1~3) 1.5
AM-1200 1.10 1~5 (suggest 1~3) 1.5
AM-1500 1.80 1~5 (suggest 1~3) 2.2
AM-1800 2.30 1~5 (suggest 1~3) 4.0
AM-2000 2.60 1~5 (suggest 1~3) 4.0
AM-2300 3.90 1~5 (suggest 1~3) 4.0
AM-2600 5.30 1~5 (suggest 1~3) 5.5
AM-2900 6.40 1~5 (suggest 1~3) 5.5



1500mm Carbon Steel Multideck Tumbler Screening Machine for Silica Sand Classification High Screening Accuracy Large Capacity 3
