3000*9000mm 1~3 Decks Large Capacity 30~50 TPH High Frequency Screen Vibratory Sieve For Silica Sand With Unbalanced Motors or Electromagnetic Vibrators for Mesh Cleaning

3000*9000mm 1~3 Decks Large Capacity 30~50 TPH High Frequency Screen Vibratory Sieve For Silica Sand With Unbalanced Motors or Electromagnetic Vibrators for Mesh Cleaning

Introduction of 3000*9000mm 1~3 Decks Large Capacity 30~50 TPH High Frequency Screen Vibratory Sieve For Silica Sand With Unbalanced Motors or Electromagnetic Vibrators for Mesh Cleaning:

For high frequency fine screen, the only screen surface vibrates, and screen box does not move. It is used for dry and wet screening and dehydration operations of 0.07~10 mm particles.

Working Principle of 3000*9000mm 1~3 Decks Large Capacity 30~50 TPH High Frequency Screen Vibratory Sieve For Silica Sand With Unbalanced Motors or Electromagnetic Vibrators for Mesh Cleaning:

  AAREAL high frequency screen uses electromagnetic vibrators or unbalanced motors as the power source, the high frequency vibration directly excites the screen, making the screen work in a near resonance state. The screen surface amplitude is 1~3mm, and the vibration strength is 2~4 times that of the general vibrating screen. Under the action of high-frequency vibration, the screen surface keeps the screen clean. Even difficult-to-screen materials can be screened with high efficiency and accuracy.

  The installation angle can be easily adjusted at any time to adapt to different material properties and different screening operations.

Features of 3000*9000mm 1~3 Decks Large Capacity 30~50 TPH High Frequency Screen Vibratory Sieve For Silica Sand With Unbalanced Motors or Electromagnetic Vibrators for Mesh Cleaning:

1. No clogged screen meshes due to to automatic cleaning;
2. Vibration amplitudes are freely adjustable;
3. No dynamic loads due to static housing;
4. Continued production even if one drive (unbalance motor or electromagnetic vibrator) breaks down;
5. Use end-tension screen structure, quick screen replacement without entering the machine;
6. Motor inspection possible during operation;
7. Optimal separation of aggregates with narrow particle size distribution;
8. Highly efficient energy transmission and therefore low energy consumption.

Technical Parameters of 3000*9000mm 1~3 Decks Large Capacity 30~50 TPH High Frequency Screen Vibratory Sieve For Silica Sand With Unbalanced Motors or Electromagnetic Vibrators for Mesh Cleaning:

• Power source: electromagnetic vibrators or unbalanced motors
• Fed by a vibrating distributor, the feeding is uniform
• Up to 4 layers of screens can complete the production of 2~5 products
• Screen Width: 1~2 m
• Screen Length: 1.5~6 m
• Screen Angle: 20°~45°, and the angle is adjustable
• Mesh Size: 0.07~10mm

Models:

WA(WAU WAF)-1015 1025 1035 1040

                           1220 1230 1240 1250

                           1530 1540 1550 1560

                           1840 1850 1860

                            2045 2060 2560 3060

WAW- 1230 1245 1260 1645 1660

                       WA model, use electromagnetic vibrators as the power source

                        WAU model, use unbalanced motors as the power source

WAF (WAUF) model, in addition to the unbalanced motors (or electromagnetic vibrators) as the power source, it is driven by two vibration motors, which can effectively reduce the height of the screening machine

 WAD (WAUD) model, it can realize the simultaneous operation of two screening machines

                              WAW model, use vibrating motors as the power source

Application:

The high frequency screen is suitable for dry and wet screening, classification, dehydration and coarse separation of fine particle materials. It is widely used in the fertilizer and compound fertilizer industry, ore dressing (iron ore, quartz sand, kaolin etc.), dewatering (coal slime dewatering, dry tailings dehydration, gold ore powder carbon recovery dehydration etc.), screening of dry material etc.
