NanoscaleRotational Flow Dynamic Membrane Ultrafiltration Machine for Petroleum Industry
Introduction:
The rotational flow dynamic membrane ultrafiltration machine can not only meet and reduce the increasing environmental treatment requirements and costs, but also reduce the traditional filtration loss of high-value products and improve operator safety. This product is increasingly being used for wastewater treatment, separation and dehydration in the production process, as well as for recycling (reuse, recycling) applications in various industries.
The full series of models and membranes (MF, UF, or NF) can meet customer needs.
Features:
1. Continuous operation;
2. Low pressure difference and continuous;
3. High concentration;
4. Rapid concentration;
5. Optimize the filtrate;
6. High output;
7. Membrane durable.
Working Principle:
AAREAL ARM series membrane filter machine is a self-cleaning on-line membrane filtration system that fluidizes the filter medium through high-speed vortex. At the same time, a low and continuous pressure drop is generated inside and outside the membrane, while completing the filtration, it also prevents the contamination of the membrane in high density, high viscosity and high solid applications. It is an ideal solution for separation, concentration, recycling, dehydration, reuse and/or treatment applications.
Technical Parameters:
Specification: 250/550/750/1010
Membrane diameter: 250/550/750/1000mm
Filter area: Max. 140 m²
Number of filter layers: up to 100 layers
Removal of molecules: up to 30000g/mol
Aperture: 0.02 microns
Application:
The rotational flow dynamic membrane ultrafiltration machine is increasingly being used for wastewater treatment, separation and dehydration in the production process, as well as for recycling (reuse, recycling) applications in various industries.
