Efficiency Reciprocating Gyratory Screen Stainless Steel Screen Decks Self cleaning Rubber Balls

Automatic Vibrating Screen Machine , Horizontal Dry Screening Equipment

Overview of Large Capacity Gyratory Screen Sifter Separator for Calcined Petroleum Coke​:

Large Capacity Gyratory Screen Sifter Separator for Calcined Petroleum Coke are self-contained production screening machines for separating dry materials according to particle size.

  The Rotex gyratory screener machines provide unusually high efficiency and capacity because they have a unique gyratory-reciprocating motion of the near-horizontal screen surface, combined with a positive screen mesh cleaning system.

Working Principle of Large Capacity Gyratory Screen Sifter Separator for Calcined Petroleum Coke​:

  Gyratory motion rapidly distributes, stratifies and separates.
  The unique gyratory motion imparts a combination of actions to the material as it passes along the screen surface. It begins with a horizontal circular motion at the feed end, gradually diminishing along the length of the machine to an elliptical path, and finally to an approximate straight-line motion at the discharge end. There is no vertical component to this motion. Thus keeping the material in constant contact with the screen surface.

1. Distributes: circular motion at feed end
The gyratory motion at the feed end of the machine immediately spreads the material across the full width of the screen surface to maximise screen utilisation – even though the feed is from a single point. At the same time, this motion stratifies the material, causing the fines to sink down against the screen surface. The particles that are appreciably smaller than the openings quickly pass through at this part of the screen.

2. Stratifies: changing to elliptical motion at center
As the circular motion diminishes into an elliptical path, the gentle near-horizontal motion causes the fine particles closer in size to the screen mesh – the near-size particles – to fall through the mesh openings.

3. Separates: straight-line motion at discharge end
The nearly linear reciprocating motion at the discharge end of the AD model gyratory screen removes those particles closest in size to the mesh openings while gently conveying the oversize material off the screen. In addition, the unique gyratory sifter ability to advance or retard material flow at the discharge end allows further fine-tuning to achieve the most efficient and accurate motion for the application.

Technical Parameters of Large Capacity Gyratory Screen Sifter Separator for Calcined Petroleum Coke​​:

Advantages of Large Capacity Gyratory Screen Sifter Separator for Calcined Petroleum Coke​:

1. Standard Base Frame for each model- Slot/tab/laser cut components for increased rigidity
2. Bottom Pan- Modular sections with standard offsets to suit layout requirements
3. Dynamic Absorber Drive- For optimum counterbalance and reduced noise, with totally enclosed, profiled guard
4. Aluminum Alloy Cover- Durable/replaceable steel clamp brackets and compensating clamp assemblies
5. Draglink Assembly- Low profile for increased safety

Installation of Large Capacity Gyratory Screen Sifter Separator for Calcined Petroleum Coke​:

1. Cable Suspension Installation:

                                                 Cable Suspension Type

2. Seat Installation:

                                                              Forward Type

                                                          Direct Discharge Type

Application of Large Capacity Gyratory Screen Sifter Separator for Calcined Petroleum Coke​:

Our gyratory screening machines are operating at hundreds of locations, screening literally thousands of different materials. While not all inclusive, the following list details some of the industries and applications where gyratory sifter is the screener of choice.

Abrasives,
Carbon Products,
Clay,
Food products: like sugar,
Pharmaceutical Applications,
Grain Cleaning,
Paper Pulp Chips,
Plastic Pellets, and
Recycling
