Overview of Tumbling Screener Machines for Aluminum Oxide:
The tumbling screener machines are also known as tumbler screen, tumbler screener, tumbler screening machine, tumbling screen machine, swing sieve, swinging sieve, shaking sieve etc. The tumbler screening machine is used for control screening, fractionating and dust removal in dry, powdered and granular products. It is typically used to sieve extremely ine and/or lightweight products, such as food flour, micronised materials, mineral powders, plastic powders etc.
The tumbler screening machine is an efficient sieving equipment which is designed to meet the large out put, high-density sieving of the manufacturers. It is the most effective simulation of artificial sieving movement (sieving precision, efficiency, service life is 5~10 times than the common cylinder sieve), for the processing of all the fine and ultra-fine powder and specialmaterials, particularly suitable for materials which are difficult to classify.
Working Principleof Tumbling Screener Machines for Aluminum Oxide:
The tumbler screening machine has a three-dimensional movement similar to the simple hand screening. This tumbling action yeilds better efficiency and a higher specific screen load as compared to vibration systems.
The tumbler screener utilizes the humanoid screening principle. To imitate the movement of artificial screening action and do three-dimensional circular motion, skillfully combine the sieving (planar circular motion) and winnowing (upward parabolic motion), establish horizontal and throwing three-dimensional tumbling movement, make the material in the screen surface appear involute spiral movement. The material takes a relatively long distance across the relative area, and the landing screen time of the material is more than 85%, improving the screen through rate. The screening accuracy is as high as 90%~99%, increasing the yield.
Important Information About Tumbling Screener Machines for Aluminum Oxide You May Want to Know:
Motion
involute spiral motion
Screening Accuracy
upto 90%~99.9%
Mesh Cleaning Method
bouncing ball cleaning, ultrasonic cleaning, brush cleaning, air cleaning, ultrasonic air cleaning, air brush cleaning
Screen Structure
whole adhesive screen, or splicing segmented screen etc.
soft rock screening will not destroy the particles original structure of the material and not easy to produce static electricity
Optional
quick clamps, pneumatic lifting devices etc.
Application
can be used for material that is flammable, explosive and easy to generate static
Featuresof Tumbling Screener Machines for Aluminum Oxide:
The tumbler screening machine uses ranges of professional designs to reach customers’ extremely demand:
1. Cleaning system with balls, air, ultrasonic is equipped to prevent blinding and maintain easily.
2. Grading up to 6 particle sizes, achieving 99% separating accuracy.
3. Reasonable acceleration, long-lasting parts, reduced maintenance.
4. Less 75 decibels noisy, the optimized balance of balance, low dynamic load on the foundation.
Technical Parametersof Tumbling Screener Machines for Aluminum Oxide:
Model
Screen Area (m²)
Layers of Screen
Motor Power (KW)
AM-600
0.28
1~5
0.25
AM-1000
0.72
1~5
1.5
AM-1200
1.10
1~5
1.5
AM-1500
1.80
1~5
2.2
AM-1800
2.30
1~5
4.0
AM-2000
2.60
1~5
4.0
AM-2300
3.90
1~5
4.0
AM-2600
5.30
1~5
5.5
AM-2900
6.40
1~5
5.5
Application of Tumbling Screener Machines:
1. Food industry
2. Dairy farming
3. Chemical Industry
4. Pharmaceutical Industry
5. Recycling and environmental
6. Plastic materials
7. Agriculture
8. Confectionery industry
9. Cement and sand
10. Metal processing industry
11. Wood industry
12. Diamond cutting and grinding tools
